Refillable TPED Aluminum Gas Cylinder (T1)
ImperialMetric
| SKU | Water Capacity | Water Capacity | Diameter | Length | Service Pressure | Oxygen Capacity | Weight | Thickness | Material |
|---|---|---|---|---|---|---|---|---|---|
| cuin | lbs | in | in | psi | cuft | lbs | in | ||
| LW90-1.00-200-TPED | 61.02 | 2.20 | 3.54 | 11.02 | 2900 | 6.97 | 3.21 | 0.232 | AA 6061 |
| SKU | Water Capacity | Diameter | Length | Service Pressure | Oxygen Capacity | Weight | Thickness | Material |
|---|---|---|---|---|---|---|---|---|
| liters | mm | mm | bar | liters | kgs | mm | ||
| LW90-1.00-200-TPED | 1.00 | 90 | 280 | 200 | 197.4 | 1.46 | 5.90 | AA 6061 |
Refillable DOT Aluminum Gas Cylinder (T1)
ImperialMetric
| SKU | Water Capacity | Water Capacity | Diameter | Length | Service Pressure | Oxygen Capacity | Weight | Thickness | Material |
|---|---|---|---|---|---|---|---|---|---|
| cuin | lbs | in | in | psi | cuft | lbs | in | ||
| LF-90-3000-1.30-DOT | 79.33 | 2.86 | 3.54 | 13.62 | 3000 | 9.38 | 4.14 | 0.244 | AA 6061 |
| SKU | Water Capacity | Diameter | Length | Service Pressure | Oxygen Capacity | Weight | Thickness | Material |
|---|---|---|---|---|---|---|---|---|
| liters | mm | mm | bar | liters | kgs | mm | ||
| LF-90-3000-1.30-DOT | 1.30 | 90 | 346 | 207 | 265.60 | 1.88 | 6.20 | AA 6061 |
Refillable TPED Steel Gas Cylinder (T1)
ImperialMetric
| SKU | Water Capacity | Water Capacity | Diameter | Length | Service Pressure | Oxygen Capacity | Weight | Thickness | Material | Base shape |
|---|---|---|---|---|---|---|---|---|---|---|
| cuin | lbs | in | in | psi | cuft | lbs | in | |||
| BXT104-2.00-210-2.55-A | 122.05 | 4.40 | 4.09 | 13.46 | 3045 | 14.63 | 6.78 | 0.100 | 34CrMo4 | Concave |
| BXT104-3.00-210-2.55-A | 183.07 | 6.60 | 4.09 | 18.70 | 3045 | 21.95 | 8.23 | 0.100 | 34CrMo4 | Concave |
| BXT116-3.00-210-2.58-A | 183.07 | 6.60 | 4.57 | 15.24 | 3045 | 21.95 | 8.71 | 0.102 | 34CrMo4 | Concave |
| BXT136-6.00-210-3.01-A | 366.14 | 13.20 | 5.35 | 21.34 | 3045 | 43.90 | 16.08 | 0.119 | 34CrMo4 | Concave |
| BXT140-6.00-300-4.50-T | 366.14 | 13.20 | 5.51 | 21.46 | 4350 | 62.71 | 21.23 | 0.177 | 34CrMo4 | Convex |
| BXT136-6.80-210-3.01-A | 414.96 | 14.96 | 5.35 | 23.70 | 3045 | 49.75 | 17.38 | 0.119 | 34CrMo4 | Concave |
| BXT140-6.80-300-4.50-T | 414.96 | 14.96 | 5.51 | 24.06 | 4350 | 71.07 | 23.78 | 0.177 | 34CrMo4 | Convex |
| BXT136-7.00-210-3.01-A | 427.17 | 15.40 | 5.35 | 24.29 | 3045 | 51.21 | 17.69 | 0.119 | 34CrMo4 | Concave |
| BXT140-7.00-300-4.50-T | 427.17 | 15.40 | 5.51 | 24.72 | 4350 | 73.16 | 24.42 | 0.177 | 34CrMo4 | Convex |
| SKU | Water Capacity | Diameter | Length | Service Pressure | Oxygen Capacity | Weight | Thickness | Material | Base shape |
|---|---|---|---|---|---|---|---|---|---|
| liters | mm | mm | bar | liters | kgs | mm | |||
| BXT104-2.00-210-2.55-A | 2.00 | 104 | 342 | 210 | 414.50 | 3.08 | 2.55 | 34CrMo4 | Concave |
| BXT104-3.00-210-2.55-A | 3.00 | 104 | 475 | 210 | 621.80 | 3.74 | 2.55 | 34CrMo4 | Concave |
| BXT116-3.00-210-2.58-A | 3.00 | 116 | 387 | 210 | 621.80 | 3.96 | 2.58 | 34CrMo4 | Concave |
| BXT136-6.00-210-3.01-A | 6.00 | 136 | 542 | 210 | 1243.50 | 7.31 | 3.01 | 34CrMo4 | Concave |
| BXT140-6.00-300-4.50-T | 6.00 | 140 | 545 | 300 | 1776.50 | 9.65 | 4.50 | 34CrMo4 | Convex |
| BXT136-6.80-210-3.01-A | 6.80 | 136 | 602 | 210 | 1409.30 | 7.90 | 3.01 | 34CrMo4 | Concave |
| BXT140-6.80-300-4.50-T | 6.80 | 140 | 611 | 300 | 2013.30 | 10.81 | 4.50 | 34CrMo4 | Convex |
| BXT136-7.00-210-3.01-A | 7.00 | 136 | 617 | 210 | 1450.80 | 8.04 | 3.01 | 34CrMo4 | Concave |
| BXT140-7.00-300-4.50-T | 7.00 | 140 | 628 | 300 | 2072.50 | 11.10 | 4.50 | 34CrMo4 | Convex |
