Beverage

Refillable TPED Aluminum Gas Cylinder (T1)

ImperialMetric

SKU	Water Capacity	Water Capacity	Diameter	Length	Service Pressure	CO2 Capacity	Weight	Thickness	Material
	cuin	lbs	in	in	psi	lbs	lbs	in
LW60-0.40-166-TPED	24.41	0.88	2.36	9.45	2407	0.59	1.01	0.126	AA 6061
LW60-0.50-166-TPED	30.51	1.10	2.36	11.26	2407	0.74	1.19	0.126	AA 6061
LW60-0.60-166-TPED	36.61	1.32	2.36	13.07	2407	0.88	1.36	0.126	AA 6061
LW90-1.34-166-TPED	81.77	2.95	3.54	13.43	2407	1.98	3.43	0.193	AA 6061
LW120-2.67-166-TPED	162.93	5.87	4.72	15.00	2407	3.96	7.13	0.260	AA 6061
LW140-5.30-166-TPED	323.43	11.66	5.51	20.51	2407	7.85	12.56	0.299	AA 6061
LW140-7.50-166-TPED	457.68	16.50	5.51	27.80	2407	11.13	16.37	0.299	AA 6061
LW203-13.40-166-TPED	817.72	29.48	7.99	25.28	2407	19.88	31.72	0.441	AA 6061

SKU	Water Capacity	Diameter	Length	Service Pressure	CO2 Capacity	Weight	Thickness	Material
	liters	mm	mm	bar	kgs	kgs	mm
LW60-0.40-166-TPED	0.40	60	240	166	0.27	0.46	3.20	AA 6061
LW60-0.50-166-TPED	0.50	60	286	166	0.34	0.54	3.20	AA 6061
LW60-0.60-166-TPED	0.60	60	332	166	0.40	0.62	3.20	AA 6061
LW90-1.34-166-TPED	1.34	90	341	166	0.90	1.56	4.90	AA 6061
LW120-2.67-166-TPED	2.67	120	381	166	1.80	3.24	6.60	AA 6061
LW140-5.30-166-TPED	5.30	140	521	166	3.57	5.71	7.60	AA 6061
LW140-7.50-166-TPED	7.50	140	706	166	5.06	7.44	7.60	AA 6061
LW203-13.40-166-TPED	13.40	203	642	166	9.04	14.42	11.20	AA 6061

Refillable DOT Aluminum Gas Cylinder (T1)

ImperialMetric

SKU	Water Capacity	Water Capacity	Diameter	Length	Service Pressure	CO2 Capacity	Weight	Thickness	Material
	cuin	lbs	in	in	psi	lbs	lbs	in
LF-111.3-2015-1.20-DOT	73.23	2.64	4.38	8.43	2015	1.78	3.50	0.203	AA 6061
LF-111.3-2015-1.30-DOT	79.33	2.86	4.38	8.94	2015	1.93	3.65	0.203	AA 6061
LF-111.3-2015-1.40-DOT	85.43	3.08	4.38	9.45	2015	2.06	3.81	0.203	AA 6061
LF-111.3-2015-1.60-DOT	97.64	3.52	4.38	10.47	2015	2.37	4.09	0.203	AA 6061
LF-111.3-2015-1.70-DOT	103.74	3.74	4.38	10.98	2015	2.50	4.25	0.203	AA 6061

SKU	Water Capacity	Diameter	Length	Service Pressure	CO2 Capacity	Weight	Thickness	Material
	liters	mm	mm	bar	kgs	kgs	mm
LF-111.3-2015-1.20-DOT	1.20	111.3	214	139	0.81	1.59	5.15	AA 6061
LF-111.3-2015-1.30-DOT	1.30	111.3	227	139	0.88	1.66	5.15	AA 6061
LF-111.3-2015-1.40-DOT	1.40	111.3	240	139	0.94	1.73	5.15	AA 6061
LF-111.3-2015-1.60-DOT	1.60	111.3	266	139	1.08	1.86	5.15	AA 6061
LF-111.3-2015-1.70-DOT	1.70	111.3	279	139	1.14	1.93	5.15	AA 6061

Refillable TPED Steel Gas Cylinder (T1)

ImperialMetric

SKU	Water Capacity	Water Capacity	Diameter	Length	Service Pressure	CO2 Capacity	Weight	Thickness	Material	Base shape
	cuin	lbs	in	in	psi	lbs	lbs	in
BXT104-2.00-210-2.55-A	122.05	4.40	4.09	13.46	3045	3.30	6.78	0.100	34CrMo4	Concave
BXT104-3.00-210-2.55-A	183.07	6.60	4.09	18.70	3045	4.95	8.23	0.100	34CrMo4	Concave
BXT116-3.00-210-2.58-A	183.07	6.60	4.57	15.24	3045	4.95	8.71	0.102	34CrMo4	Concave
BXT116-5.00-210-2.58-A	305.12	11.00	4.57	23.66	3045	8.14	10.74	0.102	34CrMo4	Concave
BXT136-5.00-210-3.01-A	305.12	11.00	5.35	18.35	3045	8.14	14.19	0.119	34CrMo4	Concave
BXT140-5.00-300-4.50-T	305.12	11.00	5.51	18.19	4350	8.14	18.04	0.177	34CrMo4	Convex
BXT136-6.70-210-3.01-A	408.86	14.74	5.35	23.43	3045	11.00	17.23	0.119	34CrMo4	Concave
BXT154-6.70-166.7-3.14-A	408.86	14.74	6.06	18.86	2418	9.90	17.86	0.124	34CrMo4	Concave
BXT136-8.00-210-3.01-A	488.19	17.60	5.35	27.28	3045	13.20	19.21	0.119	34CrMo4	Concave
BXT154-8.00-210-3.40-A	488.19	17.60	6.06	22.13	3045	13.20	20.26	0.134	34CrMo4	Concave
BXT154-8.00-166.7-3.14-A	488.19	17.60	6.06	21.93	2418	11.88	19.87	0.124	34CrMo4	Concave
BXT136-8.47-210-3.01-A	516.87	18.63	5.35	28.54	3045	13.86	20.11	0.119	34CrMo4	Concave
BXT154-8.47-210-3.40-A	516.87	18.63	6.06	22.83	3045	13.86	21.05	0.134	34CrMo4	Concave
BXT154-8.47-166.7-3.14-A	516.87	18.63	6.06	23.03	2418	12.54	20.59	0.124	34CrMo4	Concave
BXT136-10.00-210-3.01-A	610.24	22.00	5.35	33.23	3045	16.50	22.59	0.119	34CrMo4	Concave
BXT154-10.00-210-3.40-A	610.24	22.00	6.06	27.09	3045	16.50	23.83	0.134	34CrMo4	Concave
BXT154-10.00-166.7-3.14-A	610.24	22.00	6.06	26.61	2418	14.74	22.95	0.124	34CrMo4	Concave
BXT154-13.40-210-3.40-A	817.72	29.48	6.06	34.96	3045	22.00	29.35	0.134	34CrMo4	Concave
BXT154-13.40-166.7-3.14-A	817.72	29.48	6.06	34.61	2418	19.80	28.18	0.124	34CrMo4	Concave
BXT154-14.00-210-3.40-A	854.33	30.80	6.06	36.34	3045	23.10	30.34	0.134	34CrMo4	Concave
BXT154-14.00-166.7-3.14-A	854.33	30.80	6.06	36.02	2418	20.68	29.13	0.124	34CrMo4	Concave

SKU	Water Capacity	Diameter	Length	Service Pressure	CO2 Capacity	Weight	Thickness	Material	Base shape
	liters	mm	mm	bar	kgs	kgs	mm
BXT104-2.00-210-2.55-A	2.00	104	342	210	1.50	3.08	2.55	34CrMo4	Concave
BXT104-3.00-210-2.55-A	3.00	104	475	210	2.25	3.74	2.55	34CrMo4	Concave
BXT116-3.00-210-2.58-A	3.00	116	387	210	2.25	3.96	2.58	34CrMo4	Concave
BXT116-5.00-210-2.58-A	5.00	116	601	210	3.70	4.88	2.58	34CrMo4	Concave
BXT136-5.00-210-3.01-A	5.00	136	466	210	3.70	6.45	3.01	34CrMo4	Concave
BXT140-5.00-300-4.50-T	5.00	140	462	300	3.70	8.20	4.50	34CrMo4	Convex
BXT136-6.70-210-3.01-A	6.70	136	595	210	5.00	7.83	3.01	34CrMo4	Concave
BXT154-6.70-166.7-3.14-A	6.70	154	479	166.7	4.50	8.12	3.14	34CrMo4	Concave
BXT136-8.00-210-3.01-A	8.00	136	693	210	6.00	8.73	3.01	34CrMo4	Concave
BXT154-8.00-210-3.40-A	8.00	154	562	210	6.00	9.21	3.40	34CrMo4	Concave
BXT154-8.00-166.7-3.14-A	8.00	154	557	166.7	5.40	9.03	3.14	34CrMo4	Concave
BXT136-8.47-210-3.01-A	8.47	136	725	210	6.30	9.14	3.01	34CrMo4	Concave
BXT154-8.47-210-3.40-A	8.47	154	580	210	6.30	9.57	3.40	34CrMo4	Concave
BXT154-8.47-166.7-3.14-A	8.47	154	585	166.7	5.70	9.36	3.14	34CrMo4	Concave
BXT136-10.00-210-3.01-A	10.00	136	844	210	7.50	10.27	3.01	34CrMo4	Concave
BXT154-10.00-210-3.40-A	10.00	154	688	210	7.50	10.83	3.40	34CrMo4	Concave
BXT154-10.00-166.7-3.14-A	10.00	154	676	166.7	6.70	10.43	3.14	34CrMo4	Concave
BXT154-13.40-210-3.40-A	13.40	154	888	210	10.00	13.34	3.40	34CrMo4	Concave
BXT154-13.40-166.7-3.14-A	13.40	154	879	166.7	9.00	12.81	3.14	34CrMo4	Concave
BXT154-14.00-210-3.40-A	14.00	154	923	210	10.50	13.79	3.40	34CrMo4	Concave
BXT154-14.00-166.7-3.14-A	14.00	154	915	166.7	9.40	13.24	3.14	34CrMo4	Concave
