Non-Refillable TPED Welding Steel Gas Cylinder (T1)

ImperialMetric

SKU	Water Capacity	Water Capacity	Diameter	Length	Service Pressure	N2O Weight	Weight	Thickness	Material	Base shape
	cuin	lbs	in	in	psi	lbs	lbs	in
EVO-70-0.30-110-2.49-TPED	18.31	0.66	2.76	4.33	1600	0.414	0.97	0.098	Q235	Convex
EVO-70-0.30-120-2.49-TPED	18.31	0.66	2.76	4.33	1740	0.449	0.97	0.098	Q235	Convex
EVO-70-0.50-110-2.49-TPED	30.51	1.10	2.76	6.69	1600	0.689	1.58	0.098	Q235	Convex
EVO-70-0.50-120-2.49-TPED	30.51	1.10	2.76	6.69	1740	0.748	1.58	0.098	Q235	Convex
EVO-70-0.60-110-2.49-TPED	36.61	1.32	2.76	7.87	1600	0.825	1.89	0.098	Q235	Convex
EVO-70-0.60-120-2.49-TPED	36.61	1.32	2.76	7.87	1740	0.898	1.89	0.098	Q235	Convex
EVO-70-0.95-110-2.49-TPED	57.97	2.09	2.76	12.01	1600	1.307	2.97	0.098	Q235	Convex
EVO-70-0.95-120-2.49-TPED	57.97	2.09	2.76	12.01	1740	1.421	2.97	0.098	Q235	Convex
EVO-70-1.05-110-2.49-TPED	64.07	2.31	2.76	13.19	1600	1.443	3.28	0.098	Q235	Convex
EVO-70-1.05-120-2.49-TPED	64.07	2.31	2.76	13.19	1740	1.571	3.28	0.098	Q235	Convex
EVO-101-2.20-110-2.90-TPED	134.25	4.84	3.98	13.50	1600	3.025	5.83	0.114	Q235	Convex
EVO-101-2.20-120-2.90-TPED	134.25	4.84	3.98	13.50	1740	3.291	5.83	0.114	Q235	Convex
EVO-118-3.30-110-3.14-TPED	201.38	7.26	4.65	14.45	1600	4.539	8.84	0.124	Q355	Convex
EVO-118-3.30-110-3.14-TPED	201.38	7.26	4.65	14.45	1740	4.937	8.84	0.124	Q355	Convex

SKU	Water Capacity	Diameter	Length	Service Pressure	N2O Weight	Weight	Thickness	Material	Base shape
	liters	mm	mm	bar	kgs	kgs	mm
EVO-70-0.30-110-2.49-TPED	0.30	70	110	110	0.188	0.44	2.49	Q235	Convex
EVO-70-0.30-120-2.49-TPED	0.30	70	110	120	0.204	0.44	2.49	Q235	Convex
EVO-70-0.50-110-2.49-TPED	0.50	70	170	110	0.313	0.72	2.49	Q235	Convex
EVO-70-0.50-120-2.49-TPED	0.50	70	170	120	0.340	0.72	2.49	Q235	Convex
EVO-70-0.60-110-2.49-TPED	0.60	70	200	110	0.375	0.86	2.49	Q235	Convex
EVO-70-0.60-120-2.49-TPED	0.60	70	200	120	0.408	0.86	2.49	Q235	Convex
EVO-70-0.95-110-2.49-TPED	0.95	70	305	110	0.594	1.35	2.49	Q235	Convex
EVO-70-0.95-120-2.49-TPED	0.95	70	305	120	0.646	1.35	2.49	Q235	Convex
EVO-70-1.05-110-2.49-TPED	1.05	70	335	110	0.656	1.49	2.49	Q235	Convex
EVO-70-1.05-120-2.49-TPED	1.05	70	335	120	0.714	1.49	2.49	Q235	Convex
EVO-101-2.20-110-2.90-TPED	2.20	101	343	110	1.375	2.65	2.90	Q235	Convex
EVO-101-2.20-120-2.90-TPED	2.20	101	343	120	1.496	2.65	2.90	Q235	Convex
EVO-118-3.30-110-3.14-TPED	3.30	118	367	110	2.063	4.02	3.14	Q355	Convex
EVO-118-3.30-110-3.14-TPED	3.30	118	367	120	2.244	4.02	3.14	Q355	Convex

Non-Refillable DOT Welding Steel Gas Cylinder (T1)

ImperialMetric

SKU	Water Capacity	Water Capacity	Diameter	Length	Service Pressure	N2O Weight	Weight	Thickness	Material	Base shape
	cuin	lbs	in	in	psi	lbs	lbs	in
EVO-80-0.95-1600-1.90-DOT	57.97	2.09	3.15	9.25	1600	1.408	2.42	0.075	DC04	Convex

SKU	Water Capacity	Diameter	Length	Service Pressure	N2O Weight	Weight	Thickness	Material	Base shape
	liters	mm	mm	bar	kgs	kgs	mm
EVO-80-0.95-1600-1.90-DOT	0.95	80	235	110	0.64	1.1	1.9	DC04	Convex
