Refillable TPED Aluminum Gas Cylinder (T1)
ImperialMetric
| SKU | Water Capacity | Water Capacity | Diameter | Length | Service Pressure | Oxygen Capacity | Weight | Thickness | Material |
|---|---|---|---|---|---|---|---|---|---|
| cuin | lbs | in | in | psi | cuft | lbs | in | ||
| LW60-0.50-166-TPED | 30.51 | 1.10 | 2.36 | 11.26 | 2407 | 2.89 | 1.19 | 0.126 | AA 6061 |
| LW60.5-0.40-200-TPED | 24.41 | 0.88 | 2.38 | 9.53 | 2900 | 2.79 | 1.36 | 0.157 | AA 6061 |
| LW60.5-0.50-200-TPED | 30.51 | 1.10 | 2.38 | 11.42 | 2900 | 3.48 | 1.58 | 0.157 | AA 6061 |
| LW90-0.70-166-TPED | 42.72 | 1.54 | 3.54 | 8.15 | 2407 | 4.05 | 2.22 | 0.193 | AA 6061 |
| LW90-1.00-166-TPED | 61.02 | 2.20 | 3.54 | 10.63 | 2407 | 5.78 | 2.79 | 0.193 | AA 6061 |
| LW90-1.40-166-TPED | 85.43 | 3.08 | 3.54 | 13.94 | 2407 | 8.10 | 3.54 | 0.193 | AA 6061 |
| LW90-1.00-200-TPED | 61.02 | 2.20 | 3.54 | 11.02 | 2900 | 6.97 | 3.21 | 0.232 | AA 6061 |
| LW90-1.50-200-TPED | 91.54 | 3.30 | 3.54 | 15.24 | 2900 | 10.45 | 4.31 | 0.232 | AA 6061 |
| LW120-2.00-166-TPED | 122.05 | 4.40 | 4.72 | 11.93 | 2407 | 11.57 | 5.92 | 0.260 | AA 6061 |
| LW120-2.80-166-TPED | 170.87 | 6.16 | 4.72 | 15.59 | 2407 | 16.19 | 7.37 | 0.260 | AA 6061 |
| LW120-3.20-166-TPED | 195.28 | 7.04 | 4.72 | 17.40 | 2407 | 18.51 | 8.07 | 0.260 | AA 6061 |
| LW140-4.00-166-TPED | 244.10 | 8.80 | 5.51 | 16.22 | 2407 | 23.13 | 10.30 | 0.299 | AA 6061 |
| LW140-6.30-166-TPED | 384.45 | 13.86 | 5.51 | 23.82 | 2407 | 36.43 | 14.28 | 0.299 | AA 6061 |
| LW184-8.00-166-TPED | 488.19 | 17.60 | 7.24 | 19.29 | 2407 | 46.26 | 20.20 | 0.398 | AA 6061 |
| LW184-10.00-166-TPED | 610.24 | 22.00 | 7.24 | 23.07 | 2407 | 57.83 | 23.58 | 0.398 | AA 6061 |
| LW203-12.00-166-TPED | 732.29 | 26.40 | 7.99 | 23.07 | 2407 | 69.40 | 29.33 | 0.441 | AA 6061 |
| LW203-20.00-166-TPED | 1220.48 | 44.00 | 7.99 | 35.67 | 2407 | 115.66 | 43.03 | 0.441 | AA 6061 |
| SKU | Water Capacity | Diameter | Length | Service Pressure | Oxygen Capacity | Weight | Thickness | Material |
|---|---|---|---|---|---|---|---|---|
| liters | mm | mm | bar | liters | kgs | mm | ||
| LW60-0.50-166-TPED | 0.50 | 60.0 | 286 | 166 | 81.9 | 0.54 | 3.20 | AA 6061 |
| LW60.5-0.40-200-TPED | 0.40 | 60.5 | 242 | 200 | 79.0 | 0.62 | 4.00 | AA 6061 |
| LW60.5-0.50-200-TPED | 0.50 | 60.5 | 290 | 200 | 98.7 | 0.72 | 4.00 | AA 6061 |
| LW90-0.70-166-TPED | 0.70 | 90.0 | 207 | 166 | 114.7 | 1.01 | 4.90 | AA 6061 |
| LW90-1.00-166-TPED | 1.00 | 90.0 | 270 | 166 | 163.8 | 1.27 | 4.90 | AA 6061 |
| LW90-1.40-166-TPED | 1.40 | 90.0 | 354 | 166 | 229.4 | 1.61 | 4.90 | AA 6061 |
| LW90-1.00-200-TPED | 1.00 | 90.0 | 280 | 200 | 197.4 | 1.46 | 5.90 | AA 6061 |
| LW90-1.50-200-TPED | 1.50 | 90.0 | 387 | 200 | 296.1 | 1.96 | 5.90 | AA 6061 |
| LW120-2.00-166-TPED | 2.00 | 120.0 | 303 | 166 | 327.7 | 2.69 | 6.60 | AA 6061 |
| LW120-2.80-166-TPED | 2.80 | 120.0 | 396 | 166 | 458.7 | 3.35 | 6.60 | AA 6061 |
| LW120-3.20-166-TPED | 3.20 | 120.0 | 442 | 166 | 524.3 | 3.67 | 6.60 | AA 6061 |
| LW140-4.00-166-TPED | 4.00 | 140.0 | 412 | 166 | 655.3 | 4.68 | 7.60 | AA 6061 |
| LW140-6.30-166-TPED | 6.30 | 140.0 | 605 | 166 | 1032.1 | 6.49 | 7.60 | AA 6061 |
| LW184-8.00-166-TPED | 8.00 | 184.0 | 490 | 166 | 1310.6 | 9.18 | 10.10 | AA 6061 |
| LW184-10.00-166-TPED | 10.00 | 184.0 | 586 | 166 | 1638.3 | 10.72 | 10.10 | AA 6061 |
| LW203-12.00-166-TPED | 12.00 | 203.0 | 586 | 166 | 1966 | 13.33 | 11.20 | AA 6061 |
| LW203-20.00-166-TPED | 20.00 | 203.0 | 906 | 166 | 3276.6 | 19.56 | 11.20 | AA 6061 |
Refillable DOT Aluminum Gas Cylinder (T1)
ImperialMetric
| SKU | Water Capacity | Water Capacity | Diameter | Length | Service Pressure | Oxygen Capacity | Weight | Thickness | Material |
|---|---|---|---|---|---|---|---|---|---|
| cuin | lbs | in | in | psi | cuft | lbs | in | ||
| LF-81.5-2216-0.7-DOT | 42.72 | 1.54 | 3.21 | 9.45 | 2216 | 3.73 | 1.94 | 0.163 | AA 6061 |
| LF-81.5-2216-1.00-DOT | 61.02 | 2.20 | 3.21 | 12.20 | 2216 | 5.33 | 2.40 | 0.163 | AA 6061 |
| LF-90-3000-1.00-DOT | 61.02 | 2.20 | 3.54 | 11.02 | 3000 | 7.21 | 3.43 | 0.244 | AA 6061 |
| LF-90-3000-1.50-DOT | 91.54 | 3.30 | 3.54 | 15.35 | 3000 | 10.82 | 4.62 | 0.244 | AA 6061 |
| LF-111.3-2015-1.20-DOT | 73.23 | 2.64 | 4.38 | 8.43 | 2015 | 5.81 | 3.50 | 0.203 | AA 6061 |
| LF-111.3-2015-1.40-DOT | 85.43 | 3.08 | 4.38 | 9.45 | 2015 | 6.78 | 3.81 | 0.203 | AA 6061 |
| LF-111.3-2015-1.70-DOT | 103.74 | 3.74 | 4.38 | 10.98 | 2015 | 8.23 | 4.25 | 0.203 | AA 6061 |
| LF-133.4-2216-3.90-DOT | 237.99 | 8.58 | 5.25 | 16.93 | 2216 | 20.79 | 9.02 | 0.265 | AA 6061 |
| LF-133.4-2216-5.80-DOT | 353.94 | 12.76 | 5.25 | 23.82 | 2216 | 30.92 | 12.30 | 0.265 | AA 6061 |
| SKU | Water Capacity | Diameter | Length | Service Pressure | Oxygen Capacity | Weight | Thickness | Material |
|---|---|---|---|---|---|---|---|---|
| liters | mm | mm | bar | liters | kgs | mm | ||
| LF-81.5-2216-0.7-DOT | 0.70 | 81.5 | 240 | 153 | 105.7 | 0.88 | 4.15 | AA 6061 |
| LF-81.5-2216-1.00-DOT | 1.00 | 81.5 | 310 | 153 | 151.0 | 1.09 | 4.15 | AA 6061 |
| LF-90-3000-1.00-DOT | 1.00 | 90.0 | 280 | 207 | 204.3 | 1.56 | 6.20 | AA 6061 |
| LF-90-3000-1.50-DOT | 1.50 | 90.0 | 390 | 207 | 306.4 | 2.10 | 6.20 | AA 6061 |
| LF-111.3-2015-1.20-DOT | 1.20 | 111.3 | 214 | 139 | 164.6 | 1.59 | 5.15 | AA 6061 |
| LF-111.3-2015-1.40-DOT | 1.40 | 111.3 | 240 | 139 | 192.1 | 1.73 | 5.15 | AA 6061 |
| LF-111.3-2015-1.70-DOT | 1.70 | 111.3 | 279 | 139 | 233.2 | 1.93 | 5.15 | AA 6061 |
| LF-133.4-2216-3.90-DOT | 3.90 | 133.4 | 430 | 153 | 588.9 | 4.10 | 6.74 | AA 6061 |
| LF-133.4-2216-5.80-DOT | 5.80 | 133.4 | 605 | 153 | 875.8 | 5.59 | 6.74 | AA 6061 |
Refillable TPED Steel Gas Cylinder (T1)
ImperialMetric
| SKU | Water Capacity | Water Capacity | Diameter | Length | Service Pressure | Oxygen Capacity | Weight | Thickness | Material | Base shape |
|---|---|---|---|---|---|---|---|---|---|---|
| cuin | lbs | in | in | psi | cuft | lbs | in | |||
| BXT104-2.00-210-2.55-A | 122.05 | 4.40 | 4.09 | 13.46 | 3045 | 14.63 | 6.78 | 0.100 | 34CrMo4 | Concave |
| BXT104-3.00-210-2.55-A | 183.07 | 6.60 | 4.09 | 18.7 | 3045 | 21.95 | 8.23 | 0.100 | 34CrMo4 | Concave |
| BXT116-3.00-210-2.58-A | 183.07 | 6.60 | 4.57 | 15.24 | 3045 | 21.95 | 8.71 | 0.102 | 34CrMo4 | Concave |
| BXT116-5.00-210-2.58-A | 305.12 | 11.00 | 4.57 | 23.66 | 3045 | 36.58 | 10.74 | 0.102 | 34CrMo4 | Concave |
| BXT136-5.00-210-3.01-A | 305.12 | 11.00 | 5.35 | 18.35 | 3045 | 36.58 | 14.19 | 0.119 | 34CrMo4 | Concave |
| BXT140-5.00-300-4.50-T | 305.12 | 11.00 | 5.51 | 18.19 | 4350 | 52.26 | 18.04 | 0.177 | 34CrMo4 | Convex |
| BXT136-6.70-210-3.01-A | 408.86 | 14.74 | 5.35 | 23.43 | 3045 | 49.02 | 17.23 | 0.119 | 34CrMo4 | Concave |
| BXT154-6.70-166.7-3.14-A | 408.86 | 14.74 | 6.06 | 18.86 | 2418 | 38.91 | 17.86 | 0.124 | 34CrMo4 | Concave |
| BXT136-8.00-210-3.01-A | 488.19 | 17.60 | 5.35 | 27.28 | 3045 | 58.53 | 19.21 | 0.119 | 34CrMo4 | Concave |
| BXT154-8.00-210-3.40-A | 488.19 | 17.60 | 6.06 | 22.13 | 3045 | 58.53 | 20.26 | 0.134 | 34CrMo4 | Concave |
| BXT154-8.00-166.7-3.14-A | 488.19 | 17.60 | 6.06 | 21.93 | 2418 | 46.46 | 19.87 | 0.124 | 34CrMo4 | Concave |
| BXT136-8.47-210-3.01-A | 516.87 | 18.63 | 5.35 | 28.54 | 3045 | 61.97 | 20.11 | 0.119 | 34CrMo4 | Concave |
| BXT154-8.47-210-3.40-A | 516.87 | 18.63 | 6.06 | 22.83 | 3045 | 61.97 | 21.05 | 0.134 | 34CrMo4 | Concave |
| BXT154-8.47-166.7-3.14-A | 516.87 | 18.63 | 6.06 | 23.03 | 2418 | 49.19 | 20.59 | 0.124 | 34CrMo4 | Concave |
| BXT136-10.00-210-3.01-A | 610.24 | 22.00 | 5.35 | 33.23 | 3045 | 73.16 | 22.59 | 0.119 | 34CrMo4 | Concave |
| BXT154-10.00-210-3.40-A | 610.24 | 22.00 | 6.06 | 27.09 | 3045 | 73.16 | 23.83 | 0.134 | 34CrMo4 | Concave |
| BXT154-10.00-166.7-3.14-A | 610.24 | 22.00 | 6.06 | 26.61 | 2418 | 58.08 | 22.95 | 0.124 | 34CrMo4 | Concave |
| BXT154-13.40-210-3.40-A | 817.72 | 29.48 | 6.06 | 34.96 | 3045 | 98.04 | 29.35 | 0.134 | 34CrMo4 | Concave |
| BXT154-13.40-166.7-3.14-A | 817.72 | 29.48 | 6.06 | 34.61 | 2418 | 77.82 | 28.18 | 0.124 | 34CrMo4 | Concave |
| BXT154-14.00-210-3.40-A | 854.33 | 30.8 | 6.06 | 36.34 | 3045 | 102.43 | 30.34 | 0.134 | 34CrMo4 | Concave |
| BXT154-14.00-166.7-3.14-A | 854.33 | 30.8 | 6.06 | 36.02 | 2418 | 81.31 | 29.13 | 0.124 | 34CrMo4 | Concave |
| SKU | Water Capacity | Diameter | Length | Service Pressure | Oxygen Capacity | Weight | Thickness | Material | Base shape |
|---|---|---|---|---|---|---|---|---|---|
| liters | mm | mm | bar | liters | kgs | mm | |||
| BXT104-2.00-210-2.55-A | 2.00 | 104 | 342 | 210 | 414.50 | 3.08 | 2.55 | 34CrMo4 | Concave |
| BXT104-3.00-210-2.55-A | 3.00 | 104 | 475 | 210 | 621.80 | 3.74 | 2.55 | 34CrMo4 | Concave |
| BXT116-3.00-210-2.58-A | 3.00 | 116 | 387 | 210 | 621.80 | 3.96 | 2.58 | 34CrMo4 | Concave |
| BXT116-5.00-210-2.58-A | 5.00 | 116 | 601 | 210 | 1036.30 | 4.88 | 2.58 | 34CrMo4 | Concave |
| BXT136-5.00-210-3.01-A | 5.00 | 136 | 466 | 210 | 1036.30 | 6.45 | 3.01 | 34CrMo4 | Concave |
| BXT140-5.00-300-4.50-T | 5.00 | 140 | 462 | 300 | 1480.40 | 8.20 | 4.50 | 34CrMo4 | Convex |
| BXT136-6.70-210-3.01-A | 6.70 | 136 | 595 | 210 | 1388.60 | 7.83 | 3.01 | 34CrMo4 | Concave |
| BXT154-6.70-166.7-3.14-A | 6.70 | 154 | 479 | 166.7 | 1102.30 | 8.12 | 3.14 | 34CrMo4 | Concave |
| BXT136-8.00-210-3.01-A | 8.00 | 136 | 693 | 210 | 1658.00 | 8.73 | 3.01 | 34CrMo4 | Concave |
| BXT154-8.00-210-3.40-A | 8.00 | 154 | 562 | 210 | 1658.00 | 9.21 | 3.40 | 34CrMo4 | Concave |
| BXT154-8.00-166.7-3.14-A | 8.00 | 154 | 557 | 166.7 | 1316.20 | 9.03 | 3.14 | 34CrMo4 | Concave |
| BXT136-8.47-210-3.01-A | 8.47 | 136 | 725 | 210 | 1755.40 | 9.14 | 3.01 | 34CrMo4 | Concave |
| BXT154-8.47-210-3.40-A | 8.47 | 154 | 580 | 210 | 1755.40 | 9.57 | 3.40 | 34CrMo4 | Concave |
| BXT154-8.47-166.7-3.14-A | 8.47 | 154 | 585 | 166.7 | 1393.50 | 9.36 | 3.14 | 34CrMo4 | Concave |
| BXT136-10.00-210-3.01-A | 10.00 | 136 | 844 | 210 | 2072.50 | 10.27 | 3.01 | 34CrMo4 | Concave |
| BXT154-10.00-210-3.40-A | 10.00 | 154 | 688 | 210 | 2072.50 | 10.83 | 3.40 | 34CrMo4 | Concave |
| BXT154-10.00-166.7-3.14-A | 10.00 | 154 | 676 | 166.7 | 1645.20 | 10.43 | 3.14 | 34CrMo4 | Concave |
| BXT154-13.40-210-3.40-A | 13.40 | 154 | 888 | 210 | 2777.20 | 13.34 | 3.40 | 34CrMo4 | Concave |
| BXT154-13.40-166.7-3.14-A | 13.40 | 154 | 879 | 166.7 | 2204.60 | 12.81 | 3.14 | 34CrMo4 | Concave |
| BXT154-14.00-210-3.40-A | 14.00 | 154 | 923 | 210 | 2901.60 | 13.79 | 3.40 | 34CrMo4 | Concave |
| BXT154-14.00-166.7-3.14-A | 14.00 | 154 | 915 | 166.7 | 2303.30 | 13.24 | 3.14 | 34CrMo4 | Concave |
