Fire Extinguisher

Refillable PED Aluminum Gas Cylinder (T1)

ImperialMetric

SKU	CO2 Capacity	Water Capacity	Water Capacity	Diameter	Length	Service Pressure	Weight	Thickness	Material
	lbs	cuin	lbs	in	in	psi	lbs	in
EVO-LW-111-3.00-174-H	4.4	183.07	6.6	4.37	18.07	2523	6.14	0.203	AA 6061
EVO-LW-117-3.00-174-H	4.4	183.07	6.6	4.61	16.57	2523	6.31	0.214	AA 6061
EVO-LW-152-7.50-174-H	11	457.68	16.5	5.98	23.66	2523	14.85	0.278	AA 6061
EVO-LW-111-3.00-169.3-H	4.4	183.07	6.6	4.37	17.6	2455	5.37	0.178	AA 6061
EVO-LW-140-5.25-169.3-H	7.7	320.37	11.55	5.51	19.33	2455	9.39	0.224	AA 6061
EVO-LW-152-7.50-169.3-H	11	457.68	16.5	5.98	23.03	2455	13	0.243	AA 6061

SKU	CO2 Capacity	Water Capacity	Diameter	Length	Service Pressure	Weight	Thickness	Material
	kgs	liters	mm	mm	bar	kgs	mm
EVO-LW-111-3.00-174-H	2	3	111	459	174	2.79	5.16	AA 6061
EVO-LW-117-3.00-174-H	2	3	117	421	174	2.87	5.44	AA 6061
EVO-LW-152-7.50-174-H	5	7.5	152	601	174	6.75	7.06	AA 6061
EVO-LW-111-3.00-169.3-H	2	3	111	447	169.3	2.44	4.51	AA 6061
EVO-LW-140-5.25-169.3-H	3.5	5.25	140	491	169.3	4.27	5.68	AA 6061
EVO-LW-152-7.50-169.3-H	5	7.5	152	585	169.3	5.91	6.17	AA 6061

Refillable DOT Aluminum Gas Cylinder (T1)

ImperialMetric

SKU	CO2 Capacity	Water Capacity	Water Capacity	Diameter	Length	Service Pressure	Weight	Thickness	Material
	lbs	cuin	lbs	in	in	psi	lbs	in
EVO-LW-133-3.40-1800-DOT	5	207.48	7.48	5.24	14.17	1800	6.8	0.215	AA 6061
EVO-LW-175-6.70-1800-DOT	10	408.86	14.74	6.89	16.73	1800	14.04	0.283	AA 6061
EVO-LW-175-10.00-1800-DOT	15	610.24	22	6.89	23.46	1800	18.28	0.283	AA 6061
EVO-LW-203-13.40-1800-DOT	20	817.72	29.48	7.99	23.62	1800	25.04	0.328	AA 6061

SKU	CO2 Capacity	Water Capacity	Diameter	Length	Service Pressure	Weight	Thickness	Material
	kgs	liters	mm	mm	bar	kgs	mm
EVO-LW-133-3.40-1800-DOT	2.27	3.4	133	360	124	3.09	5.47	AA 6061
EVO-LW-175-6.70-1800-DOT	4.55	6.7	175	425	124	6.38	7.19	AA 6061
EVO-LW-175-10.00-1800-DOT	6.82	10	175	596	124	8.31	7.19	AA 6061
EVO-LW-203-13.40-1800-DOT	9.09	13.4	203	600	124	11.38	8.34	AA 6061

Refillable PED Steel Gas Cylinder (T1)

ImperialMetric

SKU	CO2 Capacity	Water Capacity	Water Capacity	Diameter	Length	Service Pressure	Weight	Thickness	Material	Base shape
	lbs	cuin	lbs	in	in	psi	lbs	in
BXP104-3.00-250-2.29-A	4.4	183.07	6.6	4.09	18.9	2523	8.32	0.09	34CrMo4	Concave
BXP104-3.00-250-2.29-TB	4.4	183.07	6.6	4.09	19.29	2523	8.8	0.09	34CrMo4	Convex+bottom
BXP116-3.00-250-2.38-A	4.4	183.07	6.6	4.57	15.12	2523	8.38	0.094	34CrMo4	Concave
BXP116-4.50-250-2.38-A	6.6	274.61	9.9	4.57	21.26	2523	10.47	0.094	34CrMo4	Concave
BXP136-7.50-250-2.78-A	11	457.68	16.5	5.35	25.79	2523	17.2	0.109	34CrMo4	Concave
BXP136-7.50-250-2.78-TB	11	457.68	16.5	5.35	26.38	2523	18.22	0.109	34CrMo4	Convex+bottom
BXP154-10.50-250-3.14-A	15.4	640.75	23.1	6.06	27.48	2523	23.39	0.124	34CrMo4	Concave
BXP154-10.50-250-3.14-TB	15.4	640.75	23.1	6.06	28.35	2523	24.99	0.124	34CrMo4	Convex+bottom
BXP154-15.00-250-3.14-A	22	915.36	33	6.06	38.39	2523	30.69	0.124	34CrMo4	Concave
BXP154-15.00-250-3.14-TB	22	915.36	33	6.06	38.78	2523	32.32	0.124	34CrMo4	Convex+bottom
BXP104-2.67-315-2.55-A	4.4	162.93	5.87	4.09	17.32	3133.5	7.79	0.1	34CrMo4	Concave
BXP104-2.67-315-2.55-TB	4.4	162.93	5.87	4.09	17.52	3133.5	8.23	0.1	34CrMo4	Convex+bottom
BXP116-2.67-315-2.58-A	4.4	162.93	5.87	4.57	14.37	3133.5	8.49	0.102	34CrMo4	Concave
BXP116-2.67-315-2.58-TB	4.4	162.93	5.87	4.57	14.37	3133.5	8.62	0.102	34CrMo4	Convex+bottom
BXP116-4.00-315-2.58-A	6.6	244.1	8.8	4.57	19.29	3133.5	9.72	0.102	34CrMo4	Concave
BXP116-4.00-315-2.58-TB	6.6	244.1	8.8	4.57	19.45	3133.5	10.52	0.102	34CrMo4	Convex+bottom
BXP136-6.67-315-3.01-A	11	407.03	14.67	5.35	23.35	3133.5	17.18	0.119	34CrMo4	Concave
BXP136-6.67-315-3.01-TB	11	407.03	14.67	5.35	23.74	3133.5	18.94	0.119	34CrMo4	Convex+bottom
BXP154-9.34-315-3.40-A	15.4	569.96	20.55	6.06	24.84	3133.5	22.44	0.134	34CrMo4	Concave
BXP154-9.34-315-3.40-TB	15.4	569.96	20.55	6.06	25.59	3133.5	25.17	0.134	34CrMo4	Convex+bottom

SKU	CO2 Capacity	Water Capacity	Diameter	Length	Service Pressure	Weight	Thickness	Material	Base shape
	kgs	liters	mm	mm	bar	kgs	mm
BXP104-3.00-250-2.29-A	2	3	104	480	174	3.78	2.29	34CrMo4	Concave
BXP104-3.00-250-2.29-TB	2	3	104	490	174	4	2.29	34CrMo4	Convex+bottom
BXP116-3.00-250-2.38-A	2	3	116	384	174	3.81	2.38	34CrMo4	Concave
BXP116-4.50-250-2.38-A	3	4.5	116	540	174	4.76	2.38	34CrMo4	Concave
BXP136-7.50-250-2.78-A	5	7.5	136	655	174	7.82	2.78	34CrMo4	Concave
BXP136-7.50-250-2.78-TB	5	7.5	136	670	174	8.28	2.78	34CrMo4	Convex+bottom
BXP154-10.50-250-3.14-A	7	10.5	154	698	174	10.63	3.14	34CrMo4	Concave
BXP154-10.50-250-3.14-TB	7	10.5	154	720	174	11.36	3.14	34CrMo4	Convex+bottom
BXP154-15.00-250-3.14-A	10	15	154	975	174	13.95	3.14	34CrMo4	Concave
BXP154-15.00-250-3.14-TB	10	15	154	985	174	14.69	3.14	34CrMo4	Convex+bottom
BXP104-2.67-315-2.55-A	2	2.67	104	440	216.1	3.54	2.55	34CrMo4	Concave
BXP104-2.67-315-2.55-TB	2	2.67	104	445	216.1	3.74	2.55	34CrMo4	Convex+bottom
BXP116-2.67-315-2.58-A	2	2.67	116	365	216.1	3.86	2.58	34CrMo4	Concave
BXP116-2.67-315-2.58-TB	2	2.67	116	365	216.1	3.92	2.58	34CrMo4	Convex+bottom
BXP116-4.00-315-2.58-A	3	4	116	490	216.1	4.42	2.58	34CrMo4	Concave
BXP116-4.00-315-2.58-TB	3	4	116	494	216.1	4.78	2.58	34CrMo4	Convex+bottom
BXP136-6.67-315-3.01-A	5	6.67	136	593	216.1	7.81	3.01	34CrMo4	Concave
BXP136-6.67-315-3.01-TB	5	6.67	136	603	216.1	8.61	3.01	34CrMo4	Convex+bottom
BXP154-9.34-315-3.40-A	7	9.34	154	631	216.1	10.2	3.4	34CrMo4	Concave
BXP154-9.34-315-3.40-TB	7	9.34	154	650	216.1	11.44	3.4	34CrMo4	Convex+bottom

Refillable TPED Steel Gas Cylinder (T1)

ImperialMetric

SKU	CO2 Capacity	Water Capacity	Water Capacity	Diameter	Length	Service Pressure	Weight	Thickness	Material	Base shape
	lbs	cuin	lbs	in	in	psi	lbs	in
BXT154-15.00-166.7-3.14-A	22	915.36	33	6.06	38.39	2418	30.69	0.124	34CrMo4	Concave

SKU	CO2 Capacity	Water Capacity	Diameter	Length	Service Pressure	Weight	Thickness	Material	Base shape
	kgs	liters	mm	mm	bar	kgs	mm
BXT154-15.00-166.7-3.14-A	10	15	154	975	166.7	13.95	3.14	34CrMo4	Concave
