Paintball

Refillable TPED Aluminum Gas Cylinder (T1)

ImperialMetric

SKU	Water Capacity	Water Capacity	Diameter	Length	Service Pressure	CO2 Capacity	Weight	Thickness	Material
	cuin	lbs	in	in	psi	oz	lbs	in
LW60.5-0.38-200-TPED	23.19	0.84	2.38	9.13	2900	8.81	1.32	0.157	AA 6061
LW60.5-0.40-200-TPED	24.41	0.88	2.38	9.53	2900	9.52	1.36	0.157	AA 6061
LW60.5-0.45-200-TPED	27.46	0.99	2.38	10.47	2900	10.58	1.47	0.157	AA 6061
LW60.5-0.50-200-TPED	30.51	1.10	2.38	11.42	2900	11.64	1.58	0.157	AA 6061
LW60.5-0.60-200-TPED	36.61	1.32	2.38	13.31	2900	14.10	1.80	0.157	AA 6061
LW60.5-0.70-200-TPED	42.72	1.54	2.38	15.20	2900	16.57	2.02	0.157	AA 6061
LW90-0.70-200-TPED	42.72	1.54	3.54	8.50	2900	16.57	2.55	0.232	AA 6061
LW90-0.80-200-TPED	48.82	1.76	3.54	9.33	2900	19.04	2.77	0.232	AA 6061
LW90-1.00-200-TPED	61.02	2.20	3.54	11.02	2900	23.63	3.21	0.232	AA 6061

SKU	Water Capacity	Diameter	Length	Service Pressure	CO2 Capacity	Weight	Thickness	Material
	liters	mm	mm	bar	kgs	kgs	mm
LW60.5-0.38-200-TPED	0.38	60.5	232	200	0.25	0.60	4.00	AA 6061
LW60.5-0.40-200-TPED	0.40	60.5	242	200	0.27	0.62	4.00	AA 6061
LW60.5-0.45-200-TPED	0.45	60.5	266	200	0.30	0.67	4.00	AA 6061
LW60.5-0.50-200-TPED	0.50	60.5	290	200	0.33	0.72	4.00	AA 6061
LW60.5-0.60-200-TPED	0.60	60.5	338	200	0.40	0.82	4.00	AA 6061
LW60.5-0.70-200-TPED	0.70	60.5	386	200	0.47	0.92	4.00	AA 6061
LW90-0.70-200-TPED	0.70	90.0	216	200	0.47	1.16	5.90	AA 6061
LW90-0.80-200-TPED	0.80	90.0	237	200	0.54	1.26	5.90	AA 6061
LW90-1.00-200-TPED	1.00	90.0	280	200	0.67	1.46	5.90	AA 6061

Refillable DOT Aluminum Gas Cylinder (T1)

ImperialMetric

SKU	Water Capacity	Water Capacity	Diameter	Length	Service Pressure	CO2 Capacity	Weight	Thickness	Material
	cuin	lbs	in	in	psi	oz	lbs	in
LF-61-3000-0.40-DOT	24.41	0.88	2.40	9.84	3000	9.52	1.34	0.167	AA 6061
LF-61-3000-0.45-DOT	27.46	0.99	2.40	10.79	3000	10.58	1.45	0.167	AA 6061
LF-61-3000-0.50-DOT	30.51	1.10	2.40	11.73	3000	11.64	1.58	0.167	AA 6061
LF-61-3000-0.60-DOT	36.61	1.32	2.40	13.62	3000	14.10	1.83	0.167	AA 6061
LF-61-3000-0.70-DOT	42.72	1.54	2.40	15.51	3000	16.57	2.07	0.167	AA 6061
LF-90-3000-1.00-DOT	61.02	2.20	3.54	11.02	3000	23.63	3.43	0.244	AA 6061

SKU	Water Capacity	Diameter	Length	Service Pressure	CO2 Capacity	Weight	Thickness	Material
	liters	mm	mm	bar	kgs	kgs	mm
LF-61-3000-0.40-DOT	0.40	61	250	207	0.27	0.61	4.25	AA 6061
LF-61-3000-0.45-DOT	0.45	61	274	207	0.30	0.66	4.25	AA 6061
LF-61-3000-0.50-DOT	0.50	61	298	207	0.33	0.72	4.25	AA 6061
LF-61-3000-0.60-DOT	0.60	61	346	207	0.40	0.83	4.25	AA 6061
LF-61-3000-0.70-DOT	0.70	61	394	207	0.47	0.94	4.25	AA 6061
LF-90-3000-1.00-DOT	1.00	90	280	207	0.67	1.56	6.20	AA 6061
